Products › Stainless Steel Ball Valves

An excellent quality range of Ball Valves, our clients can avail from us. This range of Ball Valves is known for its best quality and durability. Clients can avail from us this range of Ball Valves at most affordable prices.

As a complement to Neeta Valves's extensive line of Flanged Ball Valve Fully Stainless Steel, we have available in Stainless Steel a Full Port, Flanged Ball Valve.

The Neeta Valves Simple Quarter Turn Ball Valve Fully Stainless Steel has the same face to face dimensions. Easily replaces those heavy, hard to open and maintain, Cast Iron Gate Valves and is a simpler, lighter solution.

Stainless Steel Ball Valves › Sailent Features

• Stainless Steel Ball Valves
• Full Port
• Blow out proof stream
• Can be fitted with Actuator
• High Flow Capacity
• Down Stream Sealling & Floating Balls
• Quarter turn Shut off
• Mirror Finish Ball
• Longer life without maintenance
• Available in Cast Iron, Cast Steel, Stainless Steel materials

Specification | Materials of Construction
PARTS	Stainless Steel 304 / 316
BALL	Stainless Steel 304 / 316
PIN	Stainless Steel 304
SEAT	P.T.F.E. / CP.P.P.

[ Size in mm ]

Size	15	20	25	32	40	50	65	80	100
X	70	80	87	99	109	125	140	163	200
Y	46	51	57	63	77	85	95	105	131
Z	12.7	19	25.4	31.7	38.1	50.8	63.5	76.2	101.6

Technical Specification
CONSTRUCTION	Screwed End, Floating Ball, Soft Seated, Full Bore
DESIGN & MFG. STD.	As per BS 5351
INSPEC. & TESTING	As per BS 5146
FACE TO FACE	As shown
END CONNECTIONS	Screwed End BSPT/NPT/BSP/Female Ends

Notes:

• Screwed valves are of female B.S.P.N.P.T.
• Customised face to face distance can be given on customer's request.
• Illustrations, specification & data contents given above are accurateh. For continuous improvement & modifications from time to time we may change in products design and dimension without prior notice.
